95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump

    Buy cheap 95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump from wholesalers

    Buy cheap 95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump from wholesalers
    • Buy cheap 95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump from wholesalers

    95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump

    Ask Lasest Price
    Brand Name : RAMS
    Model Number : 3 Inch
    Certification : Fire protection certification
    Payment Terms : T/T, L/C
    Delivery Time : 25 work days
    • Product Details
    • Company Profile

    95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump

    3 inch High lift cast iron pump Double Cylinder Diesel engine

    MOQ:20units mixed model


    Features


    • High lift and large flow

    • Mountain pumps, irrigation, etc

    • The operation is simple

    • 2-cylinder,4-stroke,air-cooled


    APPLICATION SCOPE:
    • Agricultural production
    • Mining and metallurgical industries
    • Life water supply
    • Waterlogging and drought resistance
    • Landscaping
    • The fire application
    PowerDiesel engine
    NameHigh lift cast iron pump
    Model3X3-208-104X4-208-10
    Inlet(mm)80100
    Outle(mm)80100
    Max flow[m³/h]76103
    Max head(m)9585
    Suction(m)7
    Speed[rpm]3600
    Engine model2V882V92
    Engine type2-cylinder,4-stroke,air-cooled
    Displacemen(ml)912997
    Ratedpower[KW(Hp)]14.8(20)16(22)
    Starting systemElectric starter
    Continuous working time[h]8
    Fuel tank capacity(L)12.5
    lube oil capacity(L)2.83.5
    Overall dimension[mm]970X850X950
    Package size(mm)1030X930X1120
    Net weight(kg)149
    Gross weight(kg)190


    95m Max Head Fire Fighting Pumps 7m Suction Double Cylinder Cast Iron Pump
